Kvaser Memorator Light HS v2 編碼: 73-30130-010

產品價格：￥（人民幣）

規格：完善

發貨地：本地至全國

品牌：

最小起訂量：1個

QQ洽談點擊詢價進入商鋪

廣州智維電子科技有限公司

免費會員

會員級別：

認證類型：企業認證

企業證件：通過認證

認證信息：廣州智維電子科技有限公司

商鋪名稱：廣州智維電子科技有限公司

聯系人：周冬梅（小姐）

聯系手機：

固定電話：

企業郵箱：sales@triv.cn

聯系地址：廣州市天河區華觀路1933號萬科云城A棟303室

郵編：510640

聯系我時，請說是在焊材網上看到的，謝謝！

商品詳情

Designed for troubleshooting any CAN-based (controller area network) system, the Kvaser Memorator Light HS v2 is an easy-to-use tool for logging serial data, with no software setup required. With an autobaud function that determines CAN bus bit rate, the Kvaser Memorator Light can be attached to any high-speed CAN bus without configuration. All CAN bus traffic is logged in a circular buffer, overwriting the oldest data when the buffer becomes full. A separate circular buffer keeps track of error frame conditions and the message traffic that occurs near the conditions.

Major Features

Single high-speed CAN channel (compliant with ISO 11898-2).
Supports both 11-bit (CAN 2.0A) and 29-bit (CAN 2.0B active) identifiers.
Supports bit rates from 50 Kbit/sec up to 1 Mbit/sec.
Autobaud function determines CAN bus bit rate.
Always in silent mode - log bus traffic without interfering.
Fixed 1GB internal storage.
Two FIFO buffers; one logs all messages on the bus, the other buffer logs approximately 1000 messages before and after an error frame.
Built-in real time clock (calendar) with battery backup.
LEDs alert the user to device status.

The Kvaser Memorator Config Tool provides easy access to the recorded data when connected to the device via a USB port. The tool supports multiple formats used by popular analysis software. In addition, the extraction software allows the user to clear and reinitialize the device's memory.
