MODEL |
BASIC LOAD |
RECOMMENDED PERMISSIVE LOADS |
WEIGHT |
MAXIMUM |
||||||||||||||
|
SRJ004C |
RATINGS |
(kg) |
SWING ANGLE |
|||||||||||||||
|
C (N) |
Co (N) |
Compressive (N) |
Tensile (N) |
Radial (N) |
Moment (N-m) |
|||||||||||||
|
128 |
100 |
102 |
38.4 |
64 |
0.64 |
0.015 |
±15° |
|||||||||||
|
SRJ006C |
320 |
280 |
256 |
96 |
160 |
1.84 |
0.036 |
±30° |
||||||||||
|
SRJ008C |
490 |
540 |
392 |
147 |
245 |
3.92 |
0.06 |
±30° |
||||||||||
|
SRJ012C |
720 |
770 |
576 |
216 |
360 |
7.20 |
0.18 |
±30° |
||||||||||
|
SRJ016C |
1170 |
1300 |
936 |
351 |
585 |
18.7 |
0.37 |
±30° |
||||||||||
|
SRJ024C |
2840 |
3920 |
2272 |
852 |
1420 |
59.6 |
0.93 |
±30° |
||||||||||
|
SRJ032C |
5800 |
8820 |
4640 |
1740 |
2900 |
174 |
2.30 |
±30° |
||||||||||
|
SRJ048C |
10600 |
16000 |
8480 |
3180 |
5300 |
413 |
6.73 |
±30° |
||||||||||
|
MODEL |
A |
B |
C |
D |
E |
F |
G |
H |
I |
J |
K |
M |
N |
WIDTHK |
||||
|
ACROSS |
||||||||||||||||||
|
(units: mm) |
FLATS |
|||||||||||||||||
|
SRJ004C |
19 |
15 |
3.8 |
2.5 |
10 |
6 |
M3 x 0.5 |
3.6 |
2 |
1.5 |
2 |
6 |
1.5 |
4 |
||||
|
SRJ006C |
25 |
20 |
5.5 |
3.8 |
11.5 |
8 |
M4 x 0.5 |
4.5 |
2 |
2.3 |
3 |
10 |
2 |
5 |
||||
|
SRJ008C |
30 |
24 |
7 |
4 |
16 |
12 |
M5 x 0.5 |
5.5 |
4 |
2 |
3.4 |
11 |
2 |
7 |
||||
|
SRJ012C |
42 |
34 |
11 |
6 |
20 |
15 |
M10 x 1.5 |
11 |
2 |
3.6 |
4.3 |
14 |
2 |
14 |
||||
|
SRJ016C |
56 |
45 |
12 |
7 |
32 |
18 |
M12 x 1.75 |
12.6 |
3 |
4.6 |
5.5 |
25 |
5 |
14 |
||||
|
SRJ024C |
74 |
62 |
17 |
11 |
42 |
23 |
M14 x 2 |
15 |
5 |
5.5 |
6.6 |
35 |
7 |
17 |
||||
|
SRJ032C |
100 |
84 |
22 |
16 |
60 |
30 |
M16 x 2 |
16.6 |
6 |
8.6 |
9 |
48 |
10 |
22 |
||||
|
SRJ048C |
136 |
114 |
38 |
22 |
78 |
38 |
M28 x 2 |
30 |
6 |
10.8 |
11 |
60 |
10 |
30 |
||||
