FDK-320 立式液體全自動包裝機
技術特點：
1．采用彩色觸摸屏和穩定可靠的雙軸高精度輸出的PLC控制、制袋、計量、充填、封合、打碼、切袋一次性完成。
2．氣路控制和電路控制電箱獨立分離，噪音小，電路更穩定。
3．采用雙皮帶伺服拉膜：拉膜阻力少，包裝袋成型好，更美觀，皮帶不易磨損。
4．采用伺服控制,實現高精度定位，尺寸準確。
5．采用外置式放膜機構，包裝膜安裝更簡單、更容易。
6．包裝袋的偏差調整只需在觸摸屏上調整即可，操作簡單。
7．整機采用封閉式機構，有效防止粉塵進入機器內部。
Technical characteristics
1. PLC control with stable￡?reliable biaxial high accuracy output and color touch screen, bag-making, measuring, filling, printing,cutting , finished in one operation.
2. Separate circuit boxes for pneumatic control and power control. Noise is low, and the circuit is more stable.
3. Film-pulling with servo motor double belt: less pulling resistance, bag is formed in good shape with better appearance, belt is resistant to be worn-out.
4. Double servo control, high precision orientation, size more nicety.
5. External film releasing mechanism: simpler and easier installation of packing film.
6. Adjustment of bag deviation just needed to be controled by the touch screen. Operation is very simple .
7. Close down type mechanism , defending powder into inside of machine.
配合多種計量裝置，可包裝不同種類的物料。
Application
Suitable for many kinds of measuring equipment,and package different kinds of
可適合的配套The machine can be equipped with following devices
電腦組合秤、半自動投料裝置、螺旋式粉劑計量機、量杯式計量機、液體灌裝計量機
Electronic weighing system,semi automatic feeding device,spiral type powder measuring device and cup measuring device.
技術參數（Technical parameters）:
|
機型（Type） |
TCLB-320CB |
|
制袋長度(Bag length) |
50-150mm(L) |
|
制袋寬度(Bag width) |
30-150mm(W) |
|
薄膜寬度(Max width of roll film) |
320mm |
|
包裝速度(Packing speed) |
5-50bags/min |
|
計量范圍(Measuring range) |
500ml(Max) |
|
氣壓(Air consumption) |
0.65Mpa |
|
耗氣量(Gas consumption) |
0.4m3/min |
|
電壓（Power voltage） |
220VAC/50HZ |
|
功率（Power ） |
1.5Kw |
|
外型尺寸（Dimension） |
(L)750×(W)600×(H)1650mm |
|
機器重量（Deadwight of machin |
450KG
|
