ET 200SP連接基座 BU-SEND
上海斌勤電氣技術有限公司專業從事西門子這個品牌已經有十幾年。
在松江工業園區有一定的名聲
不要問我有沒有 西門子常規的都現貨 支持上門提貨
有需要的新老顧客歡迎上門提貨談生意（老顧客注意公司地址更改）
上海斌勤電氣技術有限公司(西門子合作伙伴）
聯系人 ：康 奎(業務經理）發布(聯系我有優惠福利哦）
地 址：上海市松江區三新北路1800弄（松江商務電子園區）24號樓5005室.
BusAdapter BA 2xRJ45
BusAdapter BA 2xFC
SIMATIC ET 200SP 的接口模塊具有一個用于總線適配器的通用 PROFINET 接口。 使用適宜的總線適配器，可根據特定應用的要求來調整連接類型：
該總線適配器的另一個優點是： 其目的是：修理出現問題的 RJ45 插座、后期轉用可靠的 FastConnect 技術或者光纖連接技術時，僅僅只需更換該適配器。
以下接口模塊通過總線適配器來提供 PROFINET 連接：
BA-Send BusAdapters are used whenever an existing ET 200SP station is to be expanded with IP67 modules of the SIMATIC ET 200AL.
The SIMATIC ET 200AL is a distributed I/O device with degree of protection IP65/67 that is easy to operate and install. Due to its high degree of protection and ruggedness as well as its small dimensions and low weight, the ET 200AL is especially suitable for use at the machine and on moving plant sections. SIMATIC ET 200AL enables the user to access digital and analog signals and IO-Link data at low cost.
In standard applications with moderate mechanical and EMC loads, SIMATIC BusAdapters with an RJ45 interface can be used, e.g. the BusAdapter BA 2xRJ45.
For machines and systems in which higher mechanical and/or EMC loads act on the devices, a SIMATIC BusAdapter with connection via FastConnect (FC) or fiber-optic cable (SCRJ or LC) is recommended. Likewise, all SIMATIC BusAdapters with a fiber-optic cable connection (SCRJ, LC) can be used with the increased loads.
BusAdapters with connections for fiber-optic cables can be used to cover high potential differences between two stations and/or high EMC loads.
An overview of the essential properties of the PN interfaces is shown in the table below
|
PN interfaces for SIMATIC BusAdapters |
Cable connection (FOC) |
max. cable length |
EMC and mechanical loading |
Can be used on devices with SIMATIC BA-interface |
|---|---|---|---|---|
|
RJ45 |
PROFINET copper cable, pluggable |
50 m |
Moderate |
All |
|
FC (FastConnect) |
PROFINET copper cable, direct connection |
50 m |
Increased 5 times |
All |
|
SCRJ |
POF (plastic) or HCS-FOC, pluggable |
50 m for POF, 100 m for HCS |
Increased 5 times |
As from IM155-6PN HF, CPU 1512SP (F) |
|
LC (Lucent Connector) |
Multi-mode glass fiber-optic cable, pluggable |
2 km |
Increased 5 times |
As from IM155-6PN HF, CPU 1512SP (F) |
可方便地將此總線適配器插到接口模塊中，然后用螺絲進行固定。
該總線適配器可配有參考標識牌。
|
商品編號 |
6ES7193-6AR00-0AA0 |
6ES7193-6AF00-0AA0 |
6ES7193-6AP00-0AA0 |
6ES7193-6AP20-0AA0 |
|
|---|---|---|---|---|---|
|
一般信息 |
|
|
|
|
|
|
產品類型標志 |
BA 2xRJ45 |
BA 2xFC |
BA 2xSCRJ |
BA SCRJ/RJ45 |
|
|
接口 |
|
|
|
|
|
|
PROFINET 接口數量 |
1 |
1 |
1; 2 個端口（交換機）SCRJ FO |
1; 2 個端口 (SCRJ + RJ45) |
|
|
PROFINET IO |
|
|
|
|
|
|
2 |
1 |
|||
|
2 |
||||
|
0 |
2 |
1 |
||
|
0 |
0 |
0 |
||
|
導線長度 |
|
|
|
|
|
|
100 m |
100 m |
|||
|
50 m |
50 m |
|||
|
250 m |
250 m |
|||
|
100 m |
100 m |
100 m |
||
|
尺寸 |
|
|
|
|
|
|
寬度 |
20 mm |
20 mm |
20 mm |
20 mm |
|
|
高度 |
69.5 mm |
69.5 mm |
69.5 mm |
||
|
深度 |
59 mm |
59 mm |
59 mm |
||
|
重量 |
|
|
|
|
|
|
重量，約 |
46 g |
53 g |
50 g |
50 g |
|
|
商品編號 |
6ES7193-6AP40-0AA0 |
6ES7193-6AG00-0AA0 |
6ES7193-6AG20-0AA0 |
6ES7193-6AG40-0AA0 |
|
|---|---|---|---|---|---|
|
一般信息 |
|
|
|
|
|
|
產品類型標志 |
BA SCRJ/FC |
BA 2xLC |
BA LC/RJ45 |
BA LC/FC |
|
|
接口 |
|
|
|
|
|
|
PROFINET 接口數量 |
1; 2 個接口 (SCRJ + FC) |
1; 2 個端口（交換機）LC 多模玻璃光纖 |
1; 2 個接口（交換機）LC / RJ45 |
||
