UTP 613 Kb unalloyed, fine grained and low alloyed steels
Classifications basic coated stick electrode
EN ISO 2560-A AWS A5.1
E 42 5 B42 H5 ~ E 7018-1 H4 R
Characteristics and field of use
UTP 613 Kb is a basis-coated stick electrode for construction-, boiler-, tube- and finegrained
steels as well as for steels with up to 0,35% C-content. It is recommended especially
for the following base metal.
UTP 613 Kb has a good weldability and a stable arc. The weld metal is resistant to ageing,
crack resistant and is little affected by steel impurities.
Base materials
Construction steels St 34 - St 60
Fine-grained-steels St E 255 - 355
Boiler steels H I - H II, 17 Mn 4
Tube steels St 35 - St 55, St 35.8, St 45.8
Cast steels GS 38 - GS 52
Typical analysis in %
C Si Mn Fe
0,07 0,4 1,1 balance
Mechanical properties of the weld metal
Yield strength RP0,2 Tensile strength Rm Elongation A Impact strength KV
MPa MPa % J
> 420 > 510 > 25 > 120
Welding instruction
Keep a short arc during the welding process. Weld dry stick electrodes only.
Re-drying: 2 – 3 h at 250 – 300 °C. Preheat weldment if necessary
Welding POSTTTIONs
Current type DC (+)
Approvals
TüV (No. 00794), DB (No. 10.138.02), ABS, BV, DNV
Form of delivery and recommended welding parameters
Electrodes Ø mm x L 2,5 x 350 3,2 x 350 4,0 x 350 5,0 x 450
Amperage 80 – 100 110 – 150 140 – 200 170 – 210
