Sensing Mode (General)Single Point Optical
Sensing Mode (Detailed)Diffuse
Housing StyleRectangular
Primary Housing MaterialMetal
Laser ClassificationClass 2
Input/OutputAnalog & Serial
IndicatorLED(s)
Analog Output Configuration4-20 mA
Max Sensing Distance (mm)150000
Minimum Sensing Distance (mm)100
Sensing BeamVisible Red Laser
Power Supply10-30 V dc
Sensing Beam Wavelength (nm)650
AdjustmentsSoftware
ConnectionIntegral QD
QD Type/Cable LengthM18 QD requires mating cordset
Number of Pins12
Analog Current Output Rating3 to 21mA
Max Discrete (Switched) Output (mA)500
Discrete (Switched) Outputs1 NPN/PNP Configurable
IP RatingIP67
Storage Temperature (°C)-20 to 70
Max Operating Temperature (°C)50
Min Operating Temperature (°C)-10
Window MaterialGlass
Minimum Response Time (ms)100
Spot Size (@ Reference Distance)< 11 mm at 10 m distance, < 35 mm at 50 m distance, < 65 mm at 100 m distance
Analog Linearity (mm)+/- 0.15%
Laser ControlYes
Power/Current Consumption (exclusive of load)< 1.5 W 11.5 W (with heating, 24 V)
